Polycrystalline Photovoltaic 255w Solar Panel/ Cheap Solar Panels China

I'm Online Chat Now
Certification
China China Poly Solar Panel Online Market certification
China China Poly Solar Panel Online Market certification
We trust the quality of your products. It always the best. Keep this going, and we will establish a long-term trade relationship with you.

—— Mr Zero

Cooperation is very satisfactory and the Company of the past few years, we are very willing to continue long-term cooperation.

—— Dean

The quality and service are good, delivery time is punctual every time.

—— Russian Seles

Polycrystalline Photovoltaic 255w Solar Panel/ Cheap Solar Panels China

large.img.alt
small.img.alt small.img.alt small.img.alt

Large Image :  Polycrystalline Photovoltaic 255w Solar Panel/ Cheap Solar Panels China Get Best Price

Product Details:
Place of Origin: China
Brand Name: Jinshi
Certification: IEC/TUV 61215, 61730; ISO 9001, CE
Model Number: NBJ-255P
Payment & Shipping Terms:
Minimum Order Quantity: 50 pcs
Price: FOB Ningbo $153/pcs (negotiable)
Packaging Details: wooden pallet with paper carton / wooden carton / according to your requirements
Delivery Time: 15 days, if samples, 7 days
Payment Terms: T/T 30% in advance, and the 70% should be paid before delivery.
Supply Ability: 1MW/month
Detailed Product Description

 Polycrystalline Photovoltaic 255w Solar Panel/ Cheap Solar Panels China

Contact: Twinkle

E-mail: wj0063@hotmail.com

Skype: sunnywong1202

Tel: 86-574-26877723

Fax: 86-574-26877727

Website: www.nbj-pvsolarpanels.com



Warranty: 10-year product guarantee;

                  12-year performance guarantee at 90% power output;

                  30-year performance guarantee at 80% power output.

Delivery time: 10-20 days after payment

Payment terms: T/T 30% in advance, and the balance 70% should be paid before delivery.

Packing: Wooden pallet

Specifications:

Solar Cells Polycrystalline Silicon Solar Cells156*156mm
Number of Cells  72 pieces
Dimension (mm) 1950*990*50mm
Weight (KG) 23

Electrical Characteristics:

Values at Standard Test Conditions STC (Air Mass AM 1.5, Irradiance 1000W/m², Cell Temperature 25ºC)

Model NBJ-260P NBJ-265P NBJ-25P
Max Power Pm(W) 260 265 255
Max Power Voltage Vmp(V) 36.07 36.15 36
Max Power Current Imp(A) 7.21 7.34 7.09
Open Circuit Voltage Voc(V) 43.3 43.4 43.2
Short Circuit Current Isc(A) 7.71 7.84 7.58
Cell Dimension (mm) 156*156 156*156 156*156
Module Dimension (mm) 1950*990*50 1950*990*50 1950*990*50
Module Efficiency (%) 13.5 13.73 13.21
Maximum System Voltage (V) DC1000 DC 1000 DC 1000
Power Tolerance (%) 0~+3 0~+3 0~+3
Series Fuse Rating (A) 15 15 15

Temperature Coefficient:

NOCT (ºC) 47 ± 2
Temperature Coefficient of Pm (%/ºC) -0.45  ± 0.05
Temperature Coefficient of Isc (%/ºC) 0.05  ± 0.01
Temperature Coefficient of Voc (%/ºC) -0.35  ± 0.02

Packing:

1*20'GP 200pcs / 5 pallets
1*40'GP 440pcs / 11 pallets
1*40'HQ 495pcs / 11 pallets

Polycrystalline Photovoltaic 255w Solar Panel/ Cheap Solar Panels China 0Polycrystalline Photovoltaic 255w Solar Panel/ Cheap Solar Panels China 1Polycrystalline Photovoltaic 255w Solar Panel/ Cheap Solar Panels China 2Polycrystalline Photovoltaic 255w Solar Panel/ Cheap Solar Panels China 3Polycrystalline Photovoltaic 255w Solar Panel/ Cheap Solar Panels China 4Polycrystalline Photovoltaic 255w Solar Panel/ Cheap Solar Panels China 5Polycrystalline Photovoltaic 255w Solar Panel/ Cheap Solar Panels China 6Polycrystalline Photovoltaic 255w Solar Panel/ Cheap Solar Panels China 7
