Dimming LED Tube Lights T5 120cm 11 Watt with clear lens milky lens home lighting
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Power:: | 15W | Input Voltage(V):: | 100-240V |
|---|---|---|---|
| Light Source: | COB LED | Color Temperature(CCT):: | Warm White (2800-3200K), Daylight (4000-5000K), Cold White (5500-6500K) |
| Water Proof:: | IP65 | Working Temperature(℃):: | -25℃ – 50℃ |
| Application:: | Factories & Offices, Parking Lot Hotels, Hospitals, Commercial Complexes | Lamp Body Material:: | Aluminum Alloy |
Dimming LED Tube Lights T5 120cm 11 Watt with clear lens milky lens home lighting
Quick Details
Item Type: LED Tube Lights 120CM 8W
Lamp Power : 11W
Input Voltage(V): AC85~265V
Lamp Luminous Flux(lm) : 750
Lamp Luminous Efficiency(lm/w) : 95
Lamp Body Material: Aluminum + PC cover
CRI (Ra>): 80
Working Temperature(℃): -25 - 50
Working Lifetime(Hour): 50000
Warranty(Years): 2
Optional:
1) Light Color: Warm White, Pure White, Cool White, Red, Green, Blue, Yellow
2) Rated Voltage: 12VDC, 85~130VAC, 180~260VAC, 50/60Hz
3) Cover type: transparent cover or foggy cover
4) PC backside or aluminum alloy backside
5) 8W, 11W, 24W are available
6) Solar power system is available
Specification
|
(Item 1) Power driver |
Parameter range |
|
LED Driver |
Internal power driver with 2 input wires |
|
Input Voltage |
100~240VAC 50/60HZ |
|
Output Voltage |
45-54VDC |
|
Operating Current |
320±5mA |
|
Input power |
11W |
|
(PF)Power Factor |
≥0.80 |
|
(EFF)Power efficiency |
≥90% |
|
(Item 2) LED tube |
Parameter range |
|
LED tube |
T5 tube 120cm length |
|
Power |
11W |
|
LED |
SMD 3528 |
|
Light color |
Warm white / cold white |
|
Color Temperature |
3500K±500K/ 6500±500K |
|
Lamp Flux |
900lm |
|
LED Luminous Efficiency (include power) |
≥75-85lm/W |
|
CIR(Ra) |
≥70 |
|
Lifespan |
>50000 Hours |
|
Light failure |
After 25000 hours , light failure ≤20% |
|
Irritation Angle |
120°±10° |
|
Material |
Aluminum heat sink, PC cover, Light transmittance 90% |
|
Cap-base |
G13 |
|
Net Weight |
0.3Kg±5% |
|
Packing Dimension |
Φ16 x 1200 mm |
|
Operating Temperature |
-30℃ ~ 55 ℃ |
|
Relative Humidity |
≤90% RH |
|
Storage condition |
-40℃~80℃ |
|
Defend Grade |
IP20 CLASS1 |
T5 tube light features
1. The light source adopts the high power SMD2835/SMD3528 LED source encapsulated by ourselves, which lower the cost very much, at the same time we can control the quality of the LED source very well.
2. Using good aluminum ally shell to speed up the heat disspaton, which guarantee the lifespan of our tube
3. Adopting cover material with more than 90% transmittance, which guarantee the high lumen of our tubes
4. High efficiency constant current power supply, the highest efficiency can reach 95% and PF > 0.95
5. Use small-chip shunt theorem lower chip driving barrier and increase its efficiency
6. A series of complete equipments and instruments make sure the reliable quality of the tubes, we believe our high quality products with competitive price is the best choice for you.
Cautions and notices when install led tube light
1. first,you should make sure to turn of the power
2. LED tube light apply to Electronic ballast fluorescent tube can’t be replaced directly, should remove the ballast and starter.
3. inductive light holder.--Tube light can be installed into the corresponding lamp holder directly before removing starter.
4. indoor only
Trade terms:
1. Lead time : normally in 7~15 days after deposit received.
2. Sample policy : Samples are always availble for each model.
Samples can be ready in 3~7 days once payment received.
3. Payment term: 30% deposit after order confirmed, the balance before shipping
by T/T , paypal, or Western Union.
4. Shipping port: Shenzhen, China
Applications
Conference / Meeting rooms
Factories & Offices, Parking lot
Hotels, Hospitals, Commercial Complexes
Residential / Institution Buildings, Schools, Colleges & Universities
Places where need energy saving and high color rendering index lighting
