Anti - Reflective Coating Monocrystalline Solar Panels 245W 1000VDC 24V

large.img.alt
small.img.alt small.img.alt small.img.alt small.img.alt

Large Image :  Anti - Reflective Coating Monocrystalline Solar Panels 245W 1000VDC 24V Get Best Price

Product Details:
Place of Origin: China
Brand Name: ZOCEN
Certification: CE, CQC, IEC, TUV, CEC, MCS, CHUBB, BV, ISO9001
Model Number: ZCM6-60P-245W
Payment & Shipping Terms:
Minimum Order Quantity: negotiation
Price: negotiation
Packaging Details: 24pcs/pallet
Delivery Time: 5-10 days
Payment Terms: Ex works, L/C, T/T, Western Union
Supply Ability: 30000pcs/month
Contact Now
Detailed Product Description
Peak Power: 245W Solar Panel Efficiency: 15.06%
Maximum System Voltage: 1000(TUV);600(UL) Frame Material: Anodized Aluminum Alloy
Glass: High Tranmission 3.2mm Tempered Glass Rear Panel: White / Black Ployester
EVA: Stone Bridge MC4: IP68
High Light:

monocrystalline solar module

,

mono crystal solar panels



Anti - Reflective Coating Monocrystalline Solar Panels 245W 1000VDC 24V







1> Descriptions

  • Product name: 245W Monocrystalline solar panels / modules / photovoltaic solar panels / PV solar panels
  • Model: ZCM6-60P-245W
  • Solar Cell: 156*156mm(6 inch) Mono-crystalline
  • Tempered Glass: 3.2mm Low Iron and Anti-reflective coating glass
  • EVA: Anti-aging,Transmittance ≥91% , Adhesive Capacity >85%
  • Back Sheet: high frame resistant & Double-sided fluorine TPT
  • Frame: Anodized aluminum alloy, Silver
  • Junction Box: 6pcs 12A Diode + 90cm 4mm2 Solar Cable
  • Life time: 25 years
  • Output cable: MC4 coonectors
  • Certificate: CE, CQC, IEC, TUV, CEC, MCS, CHUBB, BV, ISO9001



2> Features:



  • High Performance Solar Panel
  • Monocrystalline Cells
  • Low Reflection of Sunlight
  • High Light Absorption
  • Functions perfectly under low light or panel being partly shaded
  • Top Range Alloys Anodized Frame with Corner Protectors ( guaranteed no rust )
  • CHUBB insurance company to guarantee the quality



3>Quality Control

  • Robust, corrosion resistant aluminum frame independently tested to withstand wind and snow loads of up to 2400Pa and 5400Pa, respectively, ensuring mechanical stability.
  • Manufacturing facility certifed to ISO9001 Quality Management System standards.
  • Module packaging optimized to protect product during transportation and minimize on-site waste.
  • IEC61215,IEC61730,Safety Class II,conformity to CE
  • 25-year limited warranty on power output and 10-year limited warranty on materials or
    workmanship.

4> Specifications

  • 245W Monocrystalline Solar Panel Electrical Characteristics
Maximum Power(Pmax)
 245W
Power Tolerance
 0~3%
Open Circuit Voltage(Voc)
 37.20
Short Circuit Current(Isc)
 8.67
Maximum Power Voltage(Vmp)
 30.40
Maximum Power Voltage(Imp)
 8.07
Module Efficiency
 15.06%
Max. System Voltage
 1000VDC
Solar Cells

Monocrystalline156*156mm(6 inch)

Cells series
 60pcs(6*10)
Bypass Diodes
 6pcs 12A
Temperature Coefficients of Pmax
 -0.47%/°C
Temperature Coefficients of Voc
 -0.35%/°C
Temperature Coefficients of Isc
 0.05%/°C
NOTC-Nominal Operating Cell Tepm.
 45℃(±2°C)
STC Condition
 1000W/m2, AM1.5, 25°C





  • 245W Monocrystalline Solar Panel Mechanical Characteristics
Dimension
 1640*992*40(mm)
Frame
 Anodized Aluminum Alloy
Construction

Front: High transmision 3.2mmTempered glass; Rear: White PET; Encapsulant: EVA
Output cables

4.0m㎡ 12AWG cable with weatherproof connectors.cable lengths 900mm
Weight
 19.5KGS



  • 245W Monocrystalline Solar Panel Packing configuration
Container
40“HQ
Module dimension
 1640*992*40mm
Pieces per pallet
 24 4
Pallets per container
 28 14
Pieces per container
 728





5> 245W Monocrystalline Solar Panel Application

  • Solar power station
  • Rural electrification, Small home power systems
  • Power supply for traffic, security, gas industry
  • 12V and 24V battery charging systems
  • Other industrial and commercial applications
