600W Rooftop Solar Power Off Grid System With Automatic Overload Protection


Large Image :  600W Rooftop Solar Power Off Grid System With Automatic Overload Protection Get Best Price

Product Details:
Place of Origin: China
Brand Name: CESC
Certification: CE TUV
Model Number: CESC-KGP600
Payment & Shipping Terms:
Minimum Order Quantity: 50 Units
Price: Negotiation
Packaging Details: Wooden & Carton Package
Delivery Time: 12 working days
Payment Terms: TT or LC at sight
Supply Ability: 5000 units per month
Detailed Product Description
Product Name: 600W Off Grid Solar Power System Output Power: 600W
Output Voltage: 220Vac Or 110Vac Solar Panel Power: 300W * 2 Pcs
High Light:

residential solar power systems


home solar energy system

Roof  Installation 600W Off Grid Solar Power System For Solar Home Power System​





Our solar power system have those functions and characteristics as following:

1.      More higher generate efficiency than the traditional solar power system;

2.      100% rate output power, Pure sine wave output ;

3.      Automatic recognition and selection of solar energy work mode or city grid operation mode

4.      Solar generate real time using function

5.      The solar energy complementary control function

6.      The City grid complementary control function

7.      AVR City-grid voltage stabilizing function, Wide voltage input : AC140V-AC280V

8.      Unattended, automatic recovery function

a.      Undervoltage protection and undervoltage automatic recovery function

b.      overvoltage protection and overvoltage automatic recovery function

c.       Solar reverse connection protection

d.      Automatic protection when short circuit

e.      Automatic overload protection

9.      LCD intelligent display





TYPE NO: P3Y-150
QTY: 2pcs
CONNECT ARRAY: 2pcs in parallel
SPEC: CELLS: 156mm polysilicon cells*72
Pm(Wp): 150W
Vm(V): 18V
Im(A): 8.33A
Voc(V): 22.5
Isc(A): 9.08A
size(MM): 1470*680*35MM
N.W(KG): 12KG
SOLAR BRACKET Material: aluminum
SPEC: 1*2,suit for solar panels array
Install place: steel roof
CONTROLLER: Controller Mode: PWM
Solar panel input range: DC15V-DC30V
Rated voltage of solar input: DC18V
Floating charge voltage: 14.5V
Charging voltage: 12V DC
Charging current: 30A
Efficiency: 96% (Max)
INVERTER: Rated Output Power: 600W
Peak power: 200% * 1s
Working Efficiency: >83%
Output Wave: Pure Sine Wave(THD5%)
Output vltage: 220V50HZ/110V60HZ
Grid power input: 220V50HZ/110V60HZ
Switching Time: 4 ms (between grid and inverter)
Protection Functions: DC over-voltage protection/over-voltage self-revcovery
DC low-voltage protection/low-voltage self-revcovery
Overheat/short-current/overload protection
Features: AVR Functions:AC145V-275V(input),
AC198V-242V (output)
batteries can be charged by Grid and automatic supply power when Grid cut off
BATTERY Battery Type: Maintain-free Lead-acid battery
Capaticty: 12V/100AH*1 (Max:1200WH)
system voltage: 12V DC
N.W: 30kg
Size: 530mm×262mm×520mm(with wheel)
N.W: 25.7kg(do not include battery)
PV CABLE: SPEC&QTY: 4mm sq with MC4 connectors: 30m



Power Consumption for reference :


Appliance Rated Power(W) QTY (PCS) Daily Wokring Time (H) Daily Power Consumption(WH)
LED Lamps 3 5 6 90
Satellite Receiver 25 1 2 50
LCD TV 70 1 4 280
DVD 40 1 2 80
FAN 40 2 6 480
Total 230 W   980


600W Rooftop Solar Power Off Grid System With Automatic Overload Protection 0
