40W Poly solar panel


Large Image :  40W Poly solar panel Get Best Price

Product Details:
Place of Origin: China
Brand Name: BoJia
Type of cell: Poly (156*146mm)
Max Power (Pm): 40w
Max operating voltage (Vmp): 18.0V
Max operating current (Imp): 2.22A
Open circuit voltage (Voc): 21.6V
Short circuit Current (Isc): 2.42A
Number of cell (pcs): 36
Size of Module (mm): 460*666*25
Max system voltage: 1000V DC (IEC)/600 VDC(UL)
Temperature coefficients of Isc(%): ±0.1% ºC
Temperature coefficients of Voc(%): -0.38% ºC
Temperature coefficients of PM(%): -0.47% ºC
Temperature coefficients of IM(%): +0.1% ºC
Temperature coefficients of VM(%): -0.38% ºC
NOCT (Normal operating cell temperature): 47 ºC(+2 ºC)
Power tolerance: +/-3%
Weight pet piece (kg): 4.0kg
Junction box type: TUV
Connectors and cables type: TUV
Cell efficiency: 15%
Module efficiency: 12.92%
Frame (material corners etc): Aluminum
Warranty: 5 years products warranty and 25 years 80% of power
Standard test conditions: Am 1.5 1000w/m2,Temperature 25ºC
FF: 68%~72%
Operating temperature: -40 ºC~85 ºC
Payment & Shipping Terms:
Minimum Order Quantity: 5pcs
Packaging Details: Carton+Plywood pallet
Delivery Time: ETC L/T :within 20 days after receiving 30% down payment
Payment Terms: 30% deposit,70% sight of B/L copy by fax
Detailed Product Description

Product features:


High reliability with guaranteed 0 to +5W power output tolerance
Passing mechanical load test of 5400 Pa to withstand heavier snow load and 2400 Pa to withstand wind pressure
Strong frame, easy to install
High transparency tempered glass: 3.2 mm, with durable glass surface
Excellent performance under different light conditions
